This inlay is UHF inlay ISO18000-6C & EPCglobal Class I Gen 2 and H3 chip.It was made up with Aluminium + PET.We devoted ourselves to RFID many years,covering most of Europe and the Americas market.We are expecting become your long-term partner in China.

It is a high performance UHF RFID tags, which worked at 860~ 960 Mhz with Alien Higgs 3 chip embedded. As one of long read distance rfid tag, this type of tags is much suitable for identification and tracking purpose. Typical application: book tags in RFID libraries, asset labels for medical equipments, patient ID tag in medical institution.

Specification
1.Antenna Programming:aluminum etching Al(9μm)+PET(50μm)
2.Compliant Standard:ISO/IEC 18000-6C, EPC Class1 Gen2
3.Manufacturer/Chip:NXP UCODE 8/UCODE 9,H4,H7,etc
4.Protocol:ISO18000-6C
5.Frequency:860-960MHz
6.EPC Memory:128 Bits/96 Bits
7.Function:Read/Write
8.Read Distance:1~10m
9.Work Mode:Passive
10.Chip Life:write 100,000 times, save data for 50 years
11.Chip ESD Protection:2000V
